Studio FET and tube microphone in one.LCT 940
- Tube and FET microphone in one housing
- Blend tube and FET circuit at any ratio
- Studio centerpiece
- 12AX7 tube
- Remote control and power supply in one
- Multi-pattern design
Included: Shock mount, Foam windscreen , 11-pin audio cable, Protective case
Your studio FET and tube mic in the same housing.
The LCT 940 unifies the specific characteristics of a premium large diaphragm FET condenser microphone and a top-notch tube microphone.
With "Tube" you get warmth and musical harmonics, while "FET" gives you clear and nuanced sound. Blend tube and FET circuit at any ratio and find your ideal mix. The LCT 940 features a total of nine different polar patterns.
LEWITT | LCT 940
Type
Condenser, externally polarized
Acoustical operating principle
Pressure gradient transducer
Transducer Ø
25.4 mm, 1 in
Diaphragm
3 micron gold sputtered Mylar
Polar pattern
Omni, wide cardioid, cardioid, supercardioid, figure-8, four intermediate patterns
Frequency range
20 ... 20,000 Hz
Sensitivity
23 mV/Pa, -33 dBV/Pa
Self-noise
8 dB (A) FET, 12 dB (A) tube
Max. SPL for 0.5 % THD
143 dBSPL, 0 dB attenuation
Signal / noise ratio
86 dB (A) FET, 82 dB (A) tube
Dynamic range
135 dB FET, 131 dB tube
Attenuation
0 dB
-6 dB
-12 dB
-18 dBLow-cut filter
linear
40 Hz (12 dB/oct)
150 Hz (6 dB/oct)
300 Hz (6 dB/oct)Internal impedance
200 Ω
PSU - supply voltage
230 V, 50 Hz
110 V, 60 HzCurrent consumption
170 mA
Connector
Gold plated 11-pin XLR
Tube/Valve
12AX7
Microphone dimensions
192 x 60 x 46 mm, 7.5 x 2.4 x 1.8 in
PSU dimensions
250 x 150 x 70 mm, 9.8 x 5.9 x 2.8 in
Microphone enclosure
Zinc die cast
Microphone net weight
662 g, 23.3 oz
PSU net weight
1,930 g, 68.1 oz
Microphones measured according to: IEC 60268-4 | Phantom power according to: IEC 61938 | Noise measurement according to: IEC 60268-1
